4. This housing option may indicate the need for special
material main rods or mounting.
5. 0.75 lead not available above 12 inch stroke.
6. For extended temperature operation consult factory
for model number.
7. Limit switch option requires AR option.
8. This option is not sealed and is not suitable for any
environment in which contaminants come in contact
with actuator and may enter the actuator.
9. N/A with 0.1 inch lead
10. Requires customer supplied Ethernet cable through
I/O port for Class 1 Division 2 compliance only.
11. Not available with 4 inch stroke.
Rotary Motor and Gearmotor Ordering
Guide
R2M/G = Motor Type
R2M = Tritex II AC Rotary Motor
R2G = Tritex II AC Rotary Gearmotor
AAA = Frame Size
075 = 75 mm
090 = 90 mm
115 = 115 mm
BBB = Gear Ratio
Blank = R2M
Single Reduction Ratios
004 = 4:1
005 = 5:1
010 = 10:1
Double Reduction Ratios (N/A on 75 mm)
016 = 16:1 020 = 20:1
025 = 25:1 040 = 40:1
050 = 50:1 100 = 100:1
C = Shaft Type
K = Keyed
R = Smooth/Round
D = Connections
G = Standard Straight Threaded Port with Internal
Terminals, M20 x 1.5
N = NPT Threaded Port with Internal Terminals,
1/2” NPT
I = Intercontec style - Exlar Standard,
M16/M23 Style Connector
J = Embedded leads with “I” plug 3’ standard
E = Coating Options
G = Exlar Standard
F = Brake Option
S = No Brake, Standard
B = Electric Brake, 24 VDC
GG = Feedback Type
HD = Analog Hall Device
IE = Incremental Encoder, 8192 Count Resolution
AF = Absolute Feedback
HHH-HH = Motor Stators
R2M/G075 Stator Specifications
138-40 = 1 Stack, 230 VAC, 4000 rpm
238-30 = 2 Stack, 230 VAC, 3000 rpm
338-20 = 3 Stack, 230 VAC, 2000 rpm
R2M/G090 Stator Specifications
238-40 = 2 Stack, 230 VAC, 4000 rpm
238-30 = 2 Stack, 230 VAC, 3000 rpm
338-20 = 3 Stack, 230 VAC, 2000 rpm
R2M/G115 Stator Specifications
138-30 = 1 Stack, 230 VAC, 3000 rpm
238-20 = 2 Stack, 230 VAC, 2000 rpm
238-15 = 2 Stack, 230 VAC, 1500 rpm
III = Voltage
230 = 115-230 VAC, Single Phase
JJJ = Option Board
SIO = Standard I/O Interconnect
IA4 = 4-20 mA Analog I/O
COP = CANOpen w/M12 connector
CON = CANOpen, without M12 connector
1
EIP = SIO plus Ethernet/IP w/M12 connector
EIN = SIO plus Ethernet/IP without M12 connector
1
PIO = SIO plus Profinet IO w/M12 connector
PIN = SIO plus Profinet IO without M12 connector
1
TCP = SIO plus Modbus TCP w/M12 connector
TCN = SIO plus Modbus TCP w/o M12 connector
1
NOTES:
1. Requires customer supplied Ethernet cable through
I/O port for Class 1 Division 2 compliance only.
2.
For extended temperature operation, consult factory
for model number.
