PRINT WIDTH
52 mm 58 mm 64 mm 70 mm 76 mm
D
54 mm 60 mm 66 mm 72 mm 78 mm
56 mm 62 mm 68 mm 74 mm 80 mm
B.MARK POSITION
Disabled
D
= the black mark alignment is not performed
Enabled = the black mark alignment is performed
B.MARK THRESHOLD Threshold value (in percent) for the recognition of the presence of black mark by the
black mark sensor:
30% 70%
40%
D
80%
50% 90%
60%
NOTE: If the “B.Mark position” parameter is disabled, this parameter is not printed.
B.MARK DISTANCE
The numeric value of the distance is made up with the following four parameters for the
setting of three digits (two for the integer part of the number, one for the decimal part)
and of the sign:
B.MARK DISTANCE SIGN
Sign setting:
+
D
= positive distance
- = negative distance
B.MARK DISTANCE [mm x 10]
Setting the digit for tens:
0
D
2 4 6 8
1 3 5 7 9
B.MARK DISTANCE [mm x 1]
Setting the digit for units:
0
D
2 4 6 8
1 3 5 7 9
B.MARK DISTANCE [mm x .1]
Setting the digit for decimals:
0
D
2 4 6 8
1 3 5 7 9
NOTES:
For example, to set the black mark distance to 15 mm, modify the parameters as follows:
B.Mark Distance Sign = +
B.Mark Distance [mm x 10] = 1
B.Mark Distance [mm x 1] = 5
B.Mark Distance [mm x .1] = 0
If the “B.Mark Position” parameter is disabled, the parameters for the “B.Mark Distance” are not printed.
36
