Model B
A CB
A = distance between printhead and alignment sensor = 32.5 mm
B = distance between printhead and cutter = 10.5 mm
C= distance between cutter and paper outlet = 33.5 mm
Distance” parameter (see par.5.4).
For example, to set a black mark distance of 15mm between the black mark and the alignment point, the parameters must
be set on the following values:
: +
: 1
: 5
: 0
during the Setup procedure of the device (see chapter 5)
using the tool "CE PRINTER SET"
in CUSTOM/POS emulation, by using the 0x1D 0xE7 command (for more details, refer to the Commands Manual)
by driver
71
