3. PRINTER FUNCTIONS
KPM216H
403-
8F$D1$
[Name] Ticket align at cut
[Format] ASCII GS { }
Hex 1D F8
Decimal 29 248
[Description] This command searchs a paper notch and then align the ticket at cut.
[Notes]
[Reference] $1D $F6
[Example]
SF
A1$41$01$81$
[Name] Hardware reset
[Format] ASCII FS $18 $10 $14 $1A
Hex 1C C0 18 10 14 1A
Decimal 28 192 24 16 20 26
[Description] When this command is received, the printer perform an hardware reset
(like a printer power-up).
Notes] • This command is executed immediately, even when the data buffer is full
(Busy).
[Default]
[Reference]
[Example]
