4.4 Switch the device ON
KPM180H
1
Switch device On
pressing the ON/OFF key.
2
Connect the power supply cable to the device.
Use the type of electrical power supply
indicated on the label.
The green leds (front and rear) turn on
and the device is ready.
Power supply cable
(supplied)
IN DC 24V 1.5A
3
4
ON/OFF
Connect the power supply cable
to an external power supply unit.
EXTERNAL POWER
SUPPLY UNIT
(OPTIONAL)
Power supply cable
(supplied)
