10.4 Printing area
In order to print ticket containing only one notch and to not overlay printing to a notch (that will make it useless for the next
alignment), it is important to well calibrate:
the value for the paper recovery after a cut (only for models with presenter).
KPM180H (standard models), TK180
1 mm 1 mm
L
DH
PRINTED
AREA
PRINTING DIRECTION
Line of manual
tear off
Printing line
Line of manual
tear off
Printing line
L Distance between an edge of the notch and the next one, called “Inter-notch distance”.
D Automatic feed for alignment at the next notch.
To use all the notches on paper, you must comply with the following equation:
The height of the printing area (H) can be increased to make no progress on alignment (D) but no further.
114
