5.4 Printer parameters
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the device has been turned off and they are stored in non-volatile memory.
PRINTER EMULATION Available emulations for the device:
SVELTA
CUSTOM/POS
D
RS232 BAUD RATE Communication speed of the serial interface:
115200
D
9600
57600 4800
38400 2400
19200 1200
NOTE: Parameter valid only with serial interface.
RS232 DATA LENGTH Number of bit used for characters encoding:
7 bits/car
8 bits/car
D
NOTE: Parameter valid only with serial interface.
RS232 PARITY Bit for the parity control of the serial interface:
None
D
= parity bit omitted
Even = even value for parity bit
Odd = odd value for parity bit
NOTE: Parameter valid only with serial interface.
RS232 HANDSHAKING Handshaking:
XON/XOFF = software handshaking
Hardware
D
= hardware handshaking (CTS/RTS)
NOTES:
Parameter valid only with serial interface.
When the receive buffer is full, if handshaking is set to XON/XOFF, the device sends the XOFF (0x13) on the
serial port. When the receive buffer has cleared once again, if handshaking is set to XON/XOFF, the device
sends the XON (0x11) on the serial port.
BUSY CONDITION Activation mode for Busy signal:
OffLine/ RXFull = Busy signal is activated when the device is both in OffLine status and
the buffer is full
RXFull
D
= Busy signal is activated when the buffer is full
NOTE: Parameter valid only with serial interface.
63
