7.9 Character sets in SVELTA emulation
In SVELTA emulation, the device has 20 embedded fonts of varying width which may be accessed through control charac-
ters (see the Commands Manual of the device). The following list shows the font available and relative dimensions in dot:
Font HEL8PT8
(A)
Font HEL10PT8
(A)
Font HEL14PT8
(A)
Font HEL16PT8
(A)
Font 18x24 (Font 18x24 in CUSTOM/POS emulation)
Font 14x24 (Font 14x24 in CUSTOM/POS emulation)
Font 10x24 (Font 10x24 in CUSTOM/POS emulation)
Font 8x12
(B)
Fixed Font
Font 8x12-2
(B)
Fixed Font
Font 12x12
(B)
Fixed Font
Font 14x11
(B)
Fixed Font
Font 16x24
(B)
Fixed Font
Font 16x24_1
(B)
(C)
Fixed Font
Font 16x24_2
(B)
(C)
Fixed Font
Font 20x15
(B)
Fixed Font
Font 28x20
(B)
Fixed Font
Font 14x24_1
(B)
(C)
Fixed Font
Font 16x24CN
(B)
(C)
Fixed Font
Font OCRB (20x32)
(B)
Fixed Font
For further information to characters representations print the Font Test
(D)
.
NOTES:
(A)
A proportional font is a font in which different characters have different pitches (widths).
(B)
(C)
The fonts with the same name and dimension contain different characters in different positions from theirs.
(D)
During power-up, if the FF FORM FEED key is held down, the device executes the FONT TEST.
In SVELTA emulation, it is possible to use TrueType fonts. True Type fonts are printable with every angle of rotation and in
bold, reverse, italic and underlined mode.
It is possible to address the TrueType font respects the UNICODE™ standard (see www.unicode.org), by using UTF-8 or
UTF-16 encoding.
For the correct printing of the code tables, it is necessary that the selected TrueType font contains all the characters in the
97
