TK180 (plastic models)
1
Remove the connector cover
by sliding it in the direction shown.
2
Connect the power adapter (supplied) to the device and
the mains outlet. Use the type of electrical power supply
indicated on the label.
Switch device on pressing the ON/OFF key.
The display turns on and
shows the message in figure.
3
VIn 24Vdc
IN DC 24V 1.5A
ON/OFF
50
