TL60 EJ
1. Board cover
2. Paper roll holder pin
3. Paper roll holder
4. Printing head
5. Cutter group
6. Paper out
7. Paper out presence sensor
8. Ejector group
9. Unlocking hook for cutter group
10. Device chassis
11. Paper in
12. USB port
13. Status LED
14. Power supply port
15. Serial port
16. FEED key
17. PRINT key
18. Paper in presence
and black mark sensor
21 4 53
78
17 16 15 14 13 12 91011
6
18
15
