Paper thickness
63 µm ± 0.5 µm (for 55 g/m
2
paper)
85 µm ± 0.6 µm (for 80 g/m
2
paper)
Paper weight from 55 g/m
2
to 80 g/m
2
Recommended types of paper
External roll diameter
TL60 STD, TL60 EJ max 80 mm
TL80 STD max 90 mm
Paper end Not attached to roll core
Internal roll core diameter
TL60 STD, TL60 EJ 13 mm
TL80 STD 25 mm
Core type Cardboard or plastic
Minimum ticket length
(6)
TL60 STD 40 mm
TL60 EJ 80 mm
TL80 STD 30 mm
CUTTER
Paper cut
TL60 STD, TL60 EJ Total cut, Partial cut
TL80 STD Total cut
Estimated life
(2)
1 000 000 cuts
DEVICE ELECTRICAL SPECIFICATIONS
Power supply 24 Vdc ±10% (optional external power supply)
69
