Custom Audio Electronics VKP80II - Fastening Details and Screw Length Calculation

1
1 2
2
Sp
8 mm
Sp
8 mm
Note:
The reference (1) indicates the screws that must located in the two external holes in front of the printer; the refer-
ence (2) indicates the screw that must located in the center hole of the rear side of the printer.
