3.3 Connections
The following fi gures show the possible connections for device.
USB standard cable
USB
POWER SUPPLY
Standard serial cable
Power supply cable
(supplied)
RS232
ATTENTION:
In some using conditions, we recommend the installation of a ferrite core on the power supply cable.
3. INSTALLATION
18 VKP80II User Manual
