10.4 Printing area
It is important to well calibrate the height of the printing area of ticket according to the inter-notch distance, in order
to print ticket containing only one notch and to not overlay printing to a notch (that will make it useless for the next
alignment).
The following fi gure shows an example of tickets with “Notch Distance” set to 0:
AREA
STAMPATA
Linea di stampa
Linea di taglio
ADHA
L
direzione
di stampa
A “Non-printable area” = “Distance between cutter/printing head” = 11,9mm (fi xed distance)
H Distance between the fi rst and the last print line, called “Height of the printing area”.
L Distance between an edge of the notch and the next one, called “Inter-notch distance”.
D Automatic feed for alignment at the next notch.
To use all the notches on the paper, you must comply with the following equation:
H + A ≤ L
The height of the printing area (H) can be increased to make no progress on alignment (D = 0) but no further.
10. ALIGNMENT
User Manual VKP80II 71
