4.2 Paper roll insertion
At every change of paper roll, check inside the printer. To change the paper roll, proceed as follows:
1
Adjust the paper width (see previous paragraphs).
3
Insert the paper into the paper infeed opening and wait for it to load automatically.
2
Position the paper roll, so that it unrolls correctly as shown in figure.
ATTENTION:
Make sure the cut is straight.
VROOM
4. OPERATION
24 VKP80II User Manual
