3.3 Connections
KPM150H
RS232POWER SUPPLY USB
Serial standard cable
USB standard cable
Power Supply cable
(supplied)
WARNING: In some using conditions, we recommend the installation of a ferrite core on the power supply
cable and on the serial cable.
NOTE: If RS232 and USB connectors are inserted, communication port is USB.
3. INSTALLATION
User manual KPM150H-AERO 29
