8.2 Bracket printer (B202H)
For the device is available a bracket 21100000001060 (supplied as an accessory) to mount one above the other two
printers. To fi x the bracket to the bottom of the printer using four M3x6 screws not supplied.
The kit includes:
1. Connecting bracket printer.
Connecting bracket printer
MATERIAL NOT
INCLUDED
MATERIAL INCLUDED
Fixing
screw M3x6
Assembly instructions
1
Move the bracket to the bottom of the printer that is placed on top.
LF
FF
LF
FF
8. ACCESSORIES
User manual KPM150H-AERO 95
