B202H
RS232
Serial standard cable
USB standard cable
(supplied)
USB
Power supply cable
24Vdc (supplied)
B202H power supply
(supplied)
WARNING: In some using conditions, we recommend the installation of a ferrite core on the serial cable.
NOTE: If RS232 and USB connectors are inserted, communication port is USB.
3. INSTALLATION
User manual KPM150H-AERO 31
