2.4 Printer components: internal view
1 - Paper presence sensors on output
2 - Mobile sensor lower for notch
3 - Cover open sensor
4 - Sensor of paper presence
5 - Upper transparence sensor and notch
NEAR PAPER
END
FF
LF
STATUS
2
5
1
1
3
4
NOTE:
For ease of reference, for some models is represented only the printer group without the external plastic chassis.
PRODUCT LABEL
(all models)
PC = Product code (14 digits)
SN = Serial number
HW = Hardware release
PC
XXXXXXXXXXXXXX
Rx
HW
0000000000000000000
SN
