2.7 Status led fl ashes
The Status led indicates hardware status of device. Given in the table below are the various led signals and the cor-
responding printer status.
KPM150H
STATUS LED DESCRIPTION
-
OFF PRINTER OFF
GREEN
ON PRINTER ON : NO ERROR
GREEN
COMMUNICATION
STATUS
1 x RECEIVING DATA
2 x RECEIPT ERRORS
(PARITY, FRAME ERROR, OVERRUN ERROR)
3 x COMMAND NOT RECOGNIZED
4 x COMMAND RECEIPT TIME OUT
5 x NEAR PAPER END
YELLOW
RECOVERABLE
ERROR
2 x PRINT HEAD OVER HEAT
3 x PAPER END
4 x PEPER JAM
5 x POWER SUPPLY VOLTAGE INCORRECT
6 x COVER OPEN
RED
UNRECOVERABLE
ERROR
3 x RAM ERROR
4 x EEPROM ERROR
5 x CUTTER ERROR
2. DESCRIPTION
22 KPM150H-AERO User manual
