5.4 Printer parameters
This printer allows the confi guration of the parameters listed in the following table.
The parameters marked with the symbol
D
are the default values.
Settings remain active even after the printer has been turned off and they are stored in non-volatile memory.
PRINTER EMULATION Available emulations for the device:
SERVICE
D
= used only for upgrade
BTP = used for management of bag tags
RS232 BAUD RATE
Communication speed of the serial interface:
115200 38400 9600
D
2400
57600 19200 4800 1200
NOTE: Parameter valid only with serial interface.
RS232 DATA LENGTH
Number of bit used for characters encoding:
7 bits/car
8 bits/car
D
NOTE: Parameter valid only with serial interface.
RS232 PARITY
Bit for the parity control of the serial interface:
None
D
= parity bit omitted
Even = even value for parity bit
Odd = odd value for parity bit
NOTE: Parameter valid only with serial interface.
USB MASS STORAGE
Sharing mode from Mass Storage:
Disabled = sharing mode disabled
Enabled
D
= sharing mode enabled
USB ADDRESS NUMBER
Numerical address code for the univocal identifi cation of the USB device (in case of
more than a USB device connected with the same PC):
0
D
3 6 9
1 4 7
2 5 8
PRINT MODE
Printing mode:
Normal
D
= enables printing in normal writing way
Reverse = enables printing rotated 180 degrees
SPEED / QUALITY
Setting of printing speed and printing quality:
High Quality
D
Normal
High Speed
PAPER THRESHOLD
Threshold value (in percent) for the recognition of the presence of paper by the paper
presence sensor:
30% 60% 90%
40%
D
70%
50% 80%
5. CONFIGURATION
60 KPM150H-AERO User manual
