8.1 Ticket tray kit (B202H)
For the device is available a ticket tray kit 97000000000200 (supplied as an accessory). The kit makes it possible to
contain tickets from 20mm to 54mm max.
The kit includes:
1. Chute collect tickets.
2. N° 2 fastening screws.
2
1
Assembly instructions
1
Remove the frontal label by levering
with a small screwdriver.
LF
FF
8. ACCESSORIES
User manual KPM150H-AERO 93
