B202H
2
Connect the power supply cable (24Vdc)
to power supply.
1
Connect the power supply cable (24Vdc)
to the connector of the printer (see par.3.3).
LF
FF
Power Supply
VIn 24Vdc
Press the ON/OFF key.
4
ON/OFF
LF
FF
Power supply cable
24Vdc (supplied)
3
Connect the power supply cable to outlet.
Power supply cable
220Vdc
4. OPERATION
User manual KPM150H-AERO 47
