28
EXCEL V+ OPERATOR MANUAL
D2325, REV A, 2/19
On the Genesis V handpiece:
• An integrated temperature sensor and six LED temperature indicators enable thermal
monitoring of the target tissue. The sensor measures the temperature of the target tissue,
and the LEDs indicate the measured temperature. The following table shows the
temperature ranges associated with each LED:
LED Color
Temperature
Range
Red 47 - 50º C
Yellow 43 - 46º C
Yellow 39 - 42º C
Green 35 - 38º C
Green 31 - 34º C
Green 26 - 30º C
Genesis V Treatment Screen
Pulse counter reset
button
Pulse counter display
Temperature display
Illuminated laser
emission indicator
