EXCEL V+ OPERATOR MANUAL
D2325, REV A, 2/19
System Specifications
Specifications subject to change without notice.
Treatment Beam
Type High Power, Frequency-doubled Nd:YAG High Power, Long Pulse Nd:YAG
Wavelength 532 nm 1064 nm
Output 13.5 J Max. 100 J Max.
Fluence
Coolview: 1.8 to 42 J/cm
2
Genesis V: 0.5 to 2 J/cm
2
Dermastat: 6 to 40 J/cm
2
CoolView: 2 to 300 J/cm
2
Genesis V: 4 to 7 J/cm
2
Pulse Duration CoolView: 0.5 to 40 ms
Genesis V: 0.5 and 1 ms
Dermastat: 0.5 to 20 ms
CoolView: 5 to 60 ms
Genesis V: 0.3 ms
Repetition Rate CoolView: 0 Hz (single shot) to 4 Hz
Genesis V: 0 Hz (single shot) to 4 Hz, 10
Hz
Dermastat: 0 Hz (single shot) to 4 Hz
CoolView: 0 Hz (single shot) to 2 Hz
Genesis V: 0 Hz (single shot) to 10 Hz
Treatment Spot CoolView: 2 to 16 mm circular spot
Genesis V: 8 mm circular spot
Dermastat: 2 mm circular spot
CoolView: 2 to 16 mm circular spot
Genesis V: 8 mm circular spot
Delivery System CoolView and Genesis V handpieces with
user-detachable umbilical
Dermastat handpiece with shielded fiber
CoolView and Genesis V handpieces with
user-detachable umbilical
Working Distance CoolView: n/a
Genesis V: 3 to 4 cm
Dermastat: 1 to 1.5 cm
CoolView: n/a
Genesis V: 3 to 4 cm
Epidermal Cooling CoolView: User-adjustable contact sap-
phire cooling
Genesis V: n/a
Dermastat: n/a
CoolView: User-adjustable contact
sapphire cooling
Genesis V: n/a
System Cooling Self-contained water to air heat exchanger
Aiming Beam 635 nm
