CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 117
DEVICE_ID
0x90
1.5.86 DEVICE_ID
Address = 0x90
Device silicon ID
Address: 0x90
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name SILICON_ID MSB
Bits 76543210
Host Access R
Device Access RW
Bit Name SILICON_ID LSB
Bits Name Description
15 : 0 SILICON_ID Device silicon ID. The value of this bit field ranges from 0 to 65535.To know device specific value,
refer to Factory Default Values section.
