Cypress CapSense Express CY8CMBR3108 User Manual

CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 164
DEBUG_RAW_COUNT0
0xe2
1.5.126 DEBUG_RAW_COUNT0
Address = 0xe2
Debug raw count for the sensor specified in SENSOR_ID. If the sensor number mentioned in SENSOR_ID register is a dis-
abled sensor, this register reports an undefined value.
Address: 0xe2
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name RAW_COUNT MSB
Bits 76543210
Host Access R
Device Access RW
Bit Name RAW_COUNT LSB
Bits Name Description
15 : 0 RAW_COUNT Debug raw count for the sensor specified in SENSOR_ID. If the sensor number mentioned in
SENSOR_ID register is a disabled sensor, this register reports an undefined value. The value of
this bit field ranges from 0 to 65535.
