CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 163
DEBUG_BASELINE0
0xe0
1.5.125 DEBUG_BASELINE0
Address = 0xe0
Debug baseline count for the sensor specified in SENSOR_ID. If the sensor number mentioned in SENSOR_ID register is a
disabled sensor, this register reports an undefined value.
Address: 0xe0
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name BASELINE MSB
Bits 76543210
Host Access R
Device Access RW
Bit Name BASELINE LSB
Bits Name Description
15 : 0 BASELINE Debug baseline count for the sensor specified in SENSOR_ID. If the sensor number mentioned
in SENSOR_ID register is a disabled sensor, this register reports an undefined value. The value
of this bit field ranges from 0 to 65535.
