Cypress CapSense Express CY8CMBR3108 User Manual

CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 142
DIFFERENCE_COUNT_SENSOR0
0xba
1.5.104 DIFFERENCE_COUNT_SENSOR0
Address = 0xba
Capacitive sensor 0 difference count signal. If this sensor is disabled, this register's value is undefined, and should be
ignored.
Address: 0xba
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name DIFFERENCE_COUNT MSB
Bits 76543210
Host Access R
Device Access RW
Bit Name DIFFERENCE_COUNT LSB
Bits Name Description
15 : 0 DIFFERENCE_COUNT Capacitive sensor 0 difference count signal. If this sensor is disabled, this register's value is un-
defined, and should be ignored. The value ranges from 0-65535 for proximity sensor and ranges
from 0-255 for button sensor.
