Cypress CapSense Express CY8CMBR3108 User Manual

CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 83
PWM_DUTYCYCLE_CFG3
0x44
1.5.52 PWM_DUTYCYCLE_CFG3
Address = 0x44
GPO3 PWM duty cycle configuration. This register is not applicable for parts CY8CMBR3102, CY8CMBR3106S.
Address: 0x44
Bits 76543210
Host Access RW RW
Device Access RW RW
Bit Name LOW_DUTY_CYCLE HIGH_DUTY_CYCLE
Bits Name Description
7 : 4 LOW_DUTY_CYCLE PWM duty cycle to be driven on GPO3 when GPO is in logic low state. This bitfield allows 16
settings for 0% to 100% duty cycle in steps of 6.67%. The valid value of this bit field ranges from
0 to 15. This bit field is not applicable for parts CY8CMBR3102, CY8CMBR3106S.
3 : 0 HIGH_DUTY_CYCLE PWM duty cycle to be driven on GPO3 when GPO is in logic high state. This bitfield allows 16
settings for 0% to 100% duty cycle in steps of 6.67%. The valid value of this bit field ranges from
0 to 15. This bit field is not applicable for parts CY8CMBR3102, CY8CMBR3106S.
