CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 66

PROX_RESOLUTION0

0x2e

1.5.35 PROX_RESOLUTION0

Address = 0x2e

Scan resolution (units: bits) for sensor 0 when this sensor is configured as a proximity sensor

Address: 0x2e

Bits 76543210

Host Access RW RW

Device Access RW RW

Bit Name RESERVED PROX_RESOLUTION0

Bits Name Description

7 : 3 RESERVED Reserved

2 : 0 PROX_RESOLUTION0 Scan resolution (units: bits) for sensor 0 when this sensor is configured as a proximity sensor

0: 16 bit

1: 15 bit

2: 14 bit

3: 13 bit

4: 12 bit
