Cypress CapSense Express CY8CMBR3108 User Manual

CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 146
DIFFERENCE_COUNT_SENSOR4
0xc2
1.5.108 DIFFERENCE_COUNT_SENSOR4
Address = 0xc2
Capacitive sensor 4 difference count signal. If this sensor is disabled, this register's value is undefined, and should be
ignored. This register is not applicable for part CY8CMBR3102.
Address: 0xc2
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name RESERVED
Bits 76543210
Host Access R
Device Access RW
Bit Name DIFFERENCE_COUNT
Bits Name Description
15 : 8 RESERVED Reserved
7 : 0 DIFFERENCE_COUNT Capacitive sensor 4 difference count signal. If this sensor is disabled, this register's value is un-
defined, and should be ignored. The value of this bit field ranges from 0 to 255. This bit field is
not applicable for part CY8CMBR3102.
