CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 154
DIFFERENCE_COUNT_SENSOR12
0xd2
1.5.116 DIFFERENCE_COUNT_SENSOR12
Address = 0xd2
Capacitive sensor 12 difference count signal. If this sensor is disabled, this register's value is undefined, and should be
ignored. This register is not applicable for parts CY8CMBR3102, CY8CMBR3108, CY8CMBR3110.
Address: 0xd2
Bits 15 14 13 12 11 10 9 8
Host Access R
Device Access RW
Bit Name RESERVED
Bits 76543210
Host Access R
Device Access RW
Bit Name DIFFERENCE_COUNT
Bits Name Description
15 : 8 RESERVED Reserved
7 : 0 DIFFERENCE_COUNT Capacitive sensor 12 difference count signal. If this sensor is disabled, this register's value is un-
defined, and should be ignored. The value of this bit field ranges from 0 to 255. This bit field is
not applicable for parts CY8CMBR3102, CY8CMBR3108, CY8CMBR3110.
