CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 122
SNS_CP_HIGH
0x98
1.5.90 SNS_CP_HIGH (continued)
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
8 CS8 Sensor 8 Cp indication. This bit field is not applicable for parts CY8CMBR3102, CY8CMBR3108.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
7 CS7 Sensor 7 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
6 CS6 Sensor 6 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
5 CS5 Sensor 5 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
4 CS4 Sensor 4 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
3 CS3 Sensor 3 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
2 CS2 Sensor 2 Cp indication. This bit field is not applicable for part CY8CMBR3102.
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
1 CS1 Sensor 1 Cp indication
0: Cp is less than or equal to 45 pF or sensor not tested
1: Cp is greater than 45 pF
0 CS0 Sensor 0 Cp indication
0: Cp is less than or equal to 45 pF or sensor not tested (a sensor is not tested for high Cp, if a
short is detected between two sensors, or between sensor and ground or Vdd, or if the sensor
is disabled in the SENSOR_EN or SPO_CFG register)
1: Cp is greater than 45 pF
