CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 19
CY8CMBR3110
1.4.4 CY8CMBR3110 (continued)
SNS_CP_HIGH None
SNS_VDD_SHORT None
SNS_GND_SHORT None
SNS_SNS_SHORT None
CMOD_SHIELD_TEST - None
BUTTON_STAT None
LATCHED_BUTTON_STAT None
PROX_STAT - None
LATCHED_PROX_STAT - None
SYNC_COUNTER0 - None
DIFFERENCE_COUNT_SENSOR0 None
DIFFERENCE_COUNT_SENSOR1 None
DIFFERENCE_COUNT_SENSOR2 None
DIFFERENCE_COUNT_SENSOR3 None
DIFFERENCE_COUNT_SENSOR4 None
DIFFERENCE_COUNT_SENSOR5 None
DIFFERENCE_COUNT_SENSOR6 None
DIFFERENCE_COUNT_SENSOR7 None
DIFFERENCE_COUNT_SENSOR8 None
DIFFERENCE_COUNT_SENSOR9 None
GPO_DATA - None
SYNC_COUNTER1 - None
DEBUG_SENSOR_ID - None
DEBUG_CP - None
DEBUG_DIFFERENCE_COUNT0 None
DEBUG_BASELINE0 None
DEBUG_RAW_COUNT0 None
DEBUG_AVG_RAW_COUNT0 None
SYNC_COUNTER2 - None
Register 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
