CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 26
Register Mapping
SLIDER1_CFG 0x61
SLIDER1_RESOLUTION 0x62
SLIDER1_THRESHOLD 0x63
SLIDER2_CFG 0x67
SLIDER2_RESOLUTION 0x68
SLIDER2_THRESHOLD 0x69
SLIDER_LBR 0x71
SLIDER_NNT 0x72
SLIDER_NT 0x73
SCRATCHPAD0 0x7a
SCRATCHPAD1 0x7b
CONFIG_CRC 0x7e
GPO_OUTPUT_STATE 0x80
SENSOR_ID 0x82
CTRL_CMD 0x86
CTRL_CMD_STATUS 0x88
CTRL_CMD_ERR 0x89
SYSTEM_STATUS 0x8a
PREV_CTRL_CMD_CODE 0x8c
FAMILY_ID 0x8f
DEVICE_ID 0x90
DEVICE_REV 0x92
CALC_CRC 0x94
TOTAL_WORKING_SNS 0x97
SNS_CP_HIGH 0x98
SNS_VDD_SHORT 0x9a
SNS_GND_SHORT 0x9c
SNS_SNS_SHORT 0x9e
CMOD_SHIELD_TEST 0xa0
BUTTON_STAT 0xaa
LATCHED_BUTTON_STAT 0xac
PROX_STAT 0xae
LATCHED_PROX_STAT 0xaf
SLIDER1_POSITION 0xb0
LIFTOFF_SLIDER1_POSITION 0xb1
SLIDER2_POSITION 0xb2
LIFTOFF_SLIDER2_POSITION 0xb3
SYNC_COUNTER0 0xb9
DIFFERENCE_COUNT_SENSOR0 0xba
DIFFERENCE_COUNT_SENSOR1 0xbc
DIFFERENCE_COUNT_SENSOR2 0xbe
DIFFERENCE_COUNT_SENSOR3 0xc0
Register Name Address
