CapSense Express Controllers Registers TRM, Document No. 001-91082 Rev. *E 8
CY8CMBR3102
1.4.1 CY8CMBR3102 (continued)
DEVICE_CFG3 - NA 0
I2C_ADDR - NA 55
REFRESH_CTRL - NA 6
STATE_TIMEOUT - NA 10
SCRATCHPAD0 - 0
SCRATCHPAD1 - 0
CONFIG_CRC None
GPO_OUTPUT_STATE - None
SENSOR_ID - None
CTRL_CMD - None
CTRL_CMD_STATUS - None
CTRL_CMD_ERR - None
SYSTEM_STATUS - None
PREV_CTRL_CMD_CODE - None
FAMILY_ID - 154
DEVICE_ID 2561
DEVICE_REV NA 1
CALC_CRC None
TOTAL_WORKING_SNS - None
SNS_CP_HIGH None
SNS_VDD_SHORT None
SNS_GND_SHORT None
SNS_SNS_SHORT None
CMOD_SHIELD_TEST - None
BUTTON_STAT None
LATCHED_BUTTON_STAT None
PROX_STAT - None
LATCHED_PROX_STAT - None
SYNC_COUNTER0 - None
DIFFERENCE_COUNT_SENSOR0 None
DIFFERENCE_COUNT_SENSOR1 None
GPO_DATA - None
SYNC_COUNTER1 - None
DEBUG_SENSOR_ID - None
DEBUG_CP - None
Register 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
