Cypress CY7C68013 User Manual

CY7C68013
Document #: 38-08012 Rev. *A Page 28 of 48
43 33 24 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
48 38 34 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
64 49 39 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
68 53 50 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
81 66 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
100 78 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
107 85 V
CC
Power N/A V
CC
. Connect to 3.3V power source.
3 2 4 GND Ground N/A Ground.
20 19 7 GND Ground N/A Ground.
27 21 17 GND Ground N/A Ground.
49 39 19 GND Ground N/A Ground.
58 48 33 GND Ground N/A Ground.
65 50 35 GND Ground N/A Ground.
80 65 48 GND Ground N/A Ground.
93 75 GND Ground N/A Ground.
116 94 GND Ground N/A Ground.
125 99 GND Ground N/A Ground.
14 13 NC N/A N/A No-connect. This pin must be left open.
15 14 NC N/A N/A No-connect. This pin must be left open.
16 15 NC N/A N/A No-connect. This pin must be left open.
Table 4-1. FX2 Pin Descriptions
[5]
(continued)
128 100 56 Name Type Default Description
