D-Link DAP-1325-US User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Conguring Wireless Network
This configuration step is available for the Access point and Repeater modes.
1. On the Wireless Network 2.4 GHz page, in the Network name field, specify your own
name for the wireless network or leave the value suggested by the extender.
2. In the Password field, specify your own password for access to the wireless network or
leave the value suggested by the extender (WPS PIN of the device, see the barcode label).
3. You can restore the parameters of the wireless network specified before resetting to factory
defaults. To do this, click the RESTORE button.
Figure 32. The page for configuring the wireless network.
4. Click the NEXT button to continue or click the BACK button to specify other settings.
Page 38 of 92

D-Link DAP-1325-US Specifications

General

Product Type	Range Extender
Wireless Standard	802.11n
Frequency Band	2.4 GHz
Maximum Wireless Speed	300 Mbps
Maximum Data Rate	300 Mbps
Antenna Type	Internal
Antennas	2
WPS Support	Yes
Security	WPA/WPA2
Operating Humidity	10% to 90% non-condensing
Device Type	Range Extender
Wireless Standards	IEEE 802.11b/g/n
Ports	1 x 10/100 Mbps Ethernet
Dimensions	66 x 48 x 33 mm
Weight	32 g
Operating Temperature	0 to 40 °C
