DAP-1325 N300 Wi-Fi Range Extender
User Manual
Installation and Connection
9. In the opened window, in the list of available wireless networks, select the wireless network
DAP-1325 and click the Connect button.
Figure 16. The list of available networks.
10. In the opened window, enter the network key (see WPS PIN on the barcode label on the
bottom panel of the device) in the Security key field and click the OK button.
11. Wait for about 20-30 seconds. After the connection is established, the network icon will be
displayed as the signal level scale.
Now you can connect to the web-based interface of DAP-1325 for configuring all needed
parameters. To gain access to an external network (to the Internet), you also need to specify the
default gateway and the addresses of DNS servers.
!
If you perform initial configuration of the extender via Wi-Fi connection, note that
immediately after changing the wireless default settings of the extender you will need to
reconfigure the wireless connection using the newly specified settings.
Page 25 of 92
