DAP-1325 N300 Wi-Fi Range Extender
User Manual
Overview
Wireless Module Parameters
Transmitter output power
The maximum value of the transmitter
output power depends upon the radio
frequency regulations applied in your
country
· 802.11n (typical at room temperature 25 °C)
15dBm (+/-1.5 dB)
Receiver sensitivity · 802.11n (typical at PER = 10% (1000-byte PDUs) at room temperature 25 °C)
HT20
-82dBm at MCS0/8
-79dBm at MCS1/9
-77dBm at MCS2/10
-74dBm at MCS3/11
-70dBm at MCS4/12
-66dBm at MCS5/13
-65dBm at MCS6/14
-64dBm at MCS7/15
HT40
-79dBm at MCS0/8
-76dBm at MCS1/9
-74dBm at MCS2/10
-71dBm at MCS3/11
-67dBm at MCS4/12
-63dBm at MCS5/13
-62dBm at MCS6/14
-61dBm at MCS7/15
Physical Parameters
Dimensions (L x W x H)
· 51 x 49 x 98 mm (2 x 1.91 x 3.85 in)
Weight
· 97 g (0.21 lb)
Operating Environment
Power
· Input: 110 to 240 V AC, 50/60 Hz
Temperature · Operating: from 0 to 40 °C
· Storage: from -20 to 70 °C
Humidity · Operating: from 10% to 90% (non-condensing)
· Storage: from 5% to 90% (non-condensing)
Page 7 of 92
