DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
Additional
On page of the Wi-Fi / Additional section, you can define additional parameters for the WLAN of
the extender.
!
Changing parameters presented on this page may negatively affect your WLAN!
Figure 54. Additional settings of the WLAN.
The following fields are available on the page:
Parameter Description
Bandwidth
The channel bandwidth for 802.11n standard.
20MHz: 802.11n clients operate at 20MHz channels.
40MHz: 802.11n clients operate at 40MHz channels.
20/40MHz -: 802.11n clients operate at 20MHz or 40MHz channels
(the channel is combined with the previous adjacent channel).
20/40MHz +: 802.11n clients operate at 20MHz or 40MHz channels
(the channel is combined with the next adjacent channel).
TX power The transmit power (in percentage terms) of the extender.
Page 68 of 92
