D-Link DAP-1325-US User Manual

DAP-1325 N300 Wi-Fi Range Extender
User Manual
Configuring via Web-based Interface
WPS
On the Wi-Fi / WPS page, you can enable the function for configuration of the WLAN and select a
method for connection to the WLAN.
The WPS function helps to configure the protected wireless network automatically. Devices
connecting to the wireless network via the WPS function must support the WPS function.
!
The WPS function allows adding devices only to the basic wireless network of the
extender .
!
Before using the function you need to configure one of the following authentication types:
Open with no encryption, WPA-PSK or WPA2-PSK with the AES encryption method,
WPA-PSK/WPA2-PSK mixed with the AES or TKIP+AES encryption method. When
other security settings are specified, controls of the WPS page are not available .
Figure 50. The page for configuring the WPS function.
To activate the WPS function, move the Enable WPS switch to the right.
Page 58 of 92

D-Link DAP-1325-US Specifications

General

Product Type	Range Extender
Wireless Standard	802.11n
Frequency Band	2.4 GHz
Maximum Wireless Speed	300 Mbps
Maximum Data Rate	300 Mbps
Antenna Type	Internal
Antennas	2
WPS Support	Yes
Security	WPA/WPA2
Operating Humidity	10% to 90% non-condensing
Device Type	Range Extender
Wireless Standards	IEEE 802.11b/g/n
Ports	1 x 10/100 Mbps Ethernet
Dimensions	66 x 48 x 33 mm
Weight	32 g
Operating Temperature	0 to 40 °C
