D-Link DAP-1350 User Manual

50D-Link DAP-1350 User Manual
Section 3 - Configuration
LAN Settings
This section will allow you to change the local network settings of the access point and to configure the DHCP
settings.
LAN Connection
Type:
IP Address:
Subnet Mask:
Default Gateway:
Device Name:
Use the drop-down menu to select Dynamic
IP (DHCP) to automatically obtain an IP
address on the LAN/private network or select
Static IP to manually enter the IP settings.
192.168.0.50 is the default IP Address of the
DAP-1350.
255.255.255.0 is the default subnet mask.
All devices on the network must have the
same subnet mask to communicate on the
network.
Enter the IP Address of the gateway in your
network.
Enter the Device Name of the AP. It is
recommended to change the Device Name if
there is more than one D-Link device within
the subnet.

D-Link DAP-1350 Specifications

General

Maximum data transfer rate	100 Mbit/s
Wireless technology	802.11n
DHCP client	Yes
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2
Package weight	570 g
Certification	-FCC Class B, Wi-Fi, IC
LED indicators	LAN
Antenna features	Integrated antenna

Weight and Dimensions

Weight	230 g
Dimensions (WxDxH)	91.4 x 20.3 x 66 mm
