D-Link DAP-1350 User Manual

67D-Link DAP-1350 User Manual
Section 3 - Configuration
Static IP
Select Static IP if all WAN IP information is provided to you by your ISP. You will need to enter in the IP address, subnet
mask, gateway address, and DNS address(es) provided to you by your ISP.
IP Address:
Subnet Mask:
Default Gateway:
Primary DNS Server:
Secondary DNS Server:
MTU:
Clone MAC Address:
Enter the IP Address provided by your ISP
(Internet Service Provider).
255.255.255.0 is the default subnet mask.
All devices on the network must have the
same subnet mask to communicate on
the network.
Enter the IP Address of the gateway in
your network.
Enter the Primary DNS (Domain Name
System) server IP address assigned by
your ISP.
Enter the Secondary DNS (optional) server
IP address assigned by your ISP.
You may need to change the MTU
(Maximum Transmission Unit) for optimal
performance with your specific ISP. The default MTU size is 1500.
The default MAC address is set to the MAC address on the AP (Access Point). You can click the Clone Your PC’s MAC
Address button to replace the AP’s MAC address with the MAC address of your Ethernet card. It is not recommended
that you change the default MAC address unless required by your ISP.

D-Link DAP-1350 Specifications

General

Maximum data transfer rate	100 Mbit/s
Wireless technology	802.11n
DHCP client	Yes
WAN connection	Ethernet (RJ-45)
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Security algorithms	WPA, WPA2
Package weight	570 g
Certification	-FCC Class B, Wi-Fi, IC
LED indicators	LAN
Antenna features	Integrated antenna

Weight and Dimensions

Weight	230 g
Dimensions (WxDxH)	91.4 x 20.3 x 66 mm
