D-Link DAP-2360 User Manual

15D-Link DAP-2360 User Manual
Section 3 - Conguration
Conguration
To congure the DAP-2360, use a computer that is connected to the DAP-2360 with an Ethernet cable (see the Network Layout
diagram ).
Launch your web browser.
Type the IP address of the DAP-2360 in the address eld (http://192.168.0.50) and
press Enter. Make sure that the IP addresses of the DAP-2360 and your computer are
in the same subnet.
Note: If you have changed the default IP address assigned to the DAP-2360, make sure to enter the correct IP address.
Enter the user name (admin) and your password. Leave the password eld blank by default and click Login.
Note: If you have changed the password, make sure
to enter the correct password.

D-Link DAP-2360 Specifications

General

Frequency band	2.4 - 2.4835 GHz
Cabling technology	10/100Base-T(X)
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	150 Mbit/s
Quality of Service (QoS) support	Yes
Networking features	Fast Ethernet
Wireless technology	802.11b/g/n
Compliance industry standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Antenna gain level (max)	5 dBi
Internal	No
Certification	FCC, UL 2043
Interface	Ethernet
Ethernet LAN (RJ-45) ports	1
Security algorithms	128-bit WEP, 64-bit WEP, SSH, SSID, WPA, WPA2
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	0 - 40 °C
Power supply type	AC/DC
Power consumption (typical)	9 W
Package depth	272 mm
Package width	204 mm
Package height	114 mm
Package weight	1306 g
Pallet width	1200 mm
Pallet length	1100 mm
Pallet height (air)	1843 mm
Pallet gross weight (air)	323840 g
Quantity per pallet (air)	210 pc(s)
Shipping (inner) case width	294 mm
Shipping (inner) case height	244 mm
Shipping (inner) case length	600 mm
Shipping (inner) case weight	7270 g
Shipping (inner) case net weight	4500 g
Number of cartons per pallet (air)	42 pc(s)
Quantity per shipping (inner) case	5 pc(s)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	166 mm
Width	188 mm
Height	36 mm
Weight	689 g
Dimensions (WxDxH)	166 x 37 x 188 mm
