27
Figure 18
Speed/Disable:
This setting has six modes (100M Full, 100M Half, 10M Full,
10M Half, Auto, and Disable) for speed or port disable selections.
Flow Control:
This setting determines whether or not the Switch will be handling
flow control. Set FlowCtrl to Enable to avoid data transfer
overflows. If set to Disable, there is either no flow control or other
hardware/software management.
When the port is set to forced mode, the flow control will
automatically be set to Disable.
QoS:
QoS settings should be set for ports that need to have a high
priority to manage the data transfer. Set the port’s QoS to high to
determine the port will always transfer their data first.
VLAN Settings (Virtual Local Area Network)
Group individual ports into a small “Virtual” network of their own
to be independent of the other ports. To add a VLAN group, click
