D-Link DPN-101G - IP QoS Classification Rules

25D-Link DPN-101G User Manual
Section 3 - Conguration
Click Advance > IP QoS, the page shown in the following gure appears. The IP QoS page contains Classication and QoS Queue.
Click Advance > IP QoS > Classication, the page shown in the following gure appears. Here congure the classication rule to specify which
parameters are used to identify the packets and move packets to specic QoS queue.
The following table describes the parameters of this page:
IP QoS
IP QoS Classication
Field Description
Specify Trac
Classication Rules
Here you can congure the matched parameters
of classication rule. It contains IP, Protocol,
Physical Port, interface.
Classication
Results
Here you can congure the target action when
packets matched the classication rule. You
can move it to specic QoS queue and add the
specic mark.
