5D-Link DPN-101G User Manual
Section 1 - Product Overview
LED Indicative Color Status Description
POWER Green
Solid Light Power on
Light o Power o
LOS Red
Blinking Power lower than sensitivity of optical receiver
Light o Received optical power of ONU is normal
PON Green
Solid Light PON link connection is normal
Light o No Activity
LAN Green
Solid Light Link successfully
Blinking Data transmitting
Light o Link o
Front Panel
