DSL-2600U ADSL/Ethernet Router with Wi-Fi
User Manual
Configuring via Web-based Interface
Parameter Description
Keep Alive
Select the checkbox if you want the router to keep you connected to
your ISP even when the connection has been inactive for a specified
period of time. When the checkbox is selected, the LCP interval
and LCP fails fields are available. Specify the required values.
Dial on demand
Select the checkbox if you want the router to establish connection to
the Internet on demand. In the Maximum idle time field, specify a
period of inactivity (in seconds) after which the connection should
be terminated.
PPP IP extension
This option is used by some ISPs. Contact your ISP to clarify if this
checkbox needs to be enabled.
Use Static IP Address
Select the checkbox if you want to use a static IP address to access
the Internet. In the Static IP Address field displayed when the
checkbox is selected, specify a static IP address.
PPP debug
Select the checkbox if you want to log all data on PPP connection
debugging.
PPPoE pass through
Displayed for the PPPoE type only.
Select the checkbox if you want to allow PPPoE clients of
computers from your LAN to connect to the Internet through this
PPPoE connection of the router.
Click the Next button to continue.
If needed, change the connection settings available in the Miscellaneous section.
Figure 27. Configuring PPPoE WAN connection.
Page 34 of 112
